Automotive 5.5" 720*1280 IPS TFT Touch Display Module MIPI interface G+G CTP Touch

This 5.5 inch touch display module with resolution of 720*1280 and an aspect ratio of 9:16, portrait mode. The 5.5 inch display AA size is 68.04×120.96 mm, and module dimension is 70.34×128.70×1.84 mm. Adopting IPS wide-view technology, the display delivers a viewing angle of 85°/85°/85°/85°. Bulit with ST7703V1 driver IC and a standard 24PIN MIPI interface, the 5.5 inch IPS TFT display ensures efficient and stable signal transmission.

For the touch solution, it features the industry mainstream G+G capacitive touch structure. It integrates GT911 (RX12*TX22) touch driver IC and adopts a universal I2C interface, which brings sensitive touch response and strong anti-interference performance.

Product Specification:

Product Drawing：

Product Features:

Classic Portable-Device Size:

• The 5.5 inch TFT display is a classic portable size, offering comfortable grip, flexible installation and great compatibility with cutouts of compact devices.

High Resolution:

• With 720×1280 resolution and 9:16 standard portrait ratio, the 5.5 inch IPS TFT Display natively adapts to UIs, applications and scanning interfaces.

Wide Viewing Angle：

• The 85° full-view IPS panel presents clear images without color distortion from all directions.

Effective Driver ICs and Interface:

• Powered by ST7703V1 and GT911 driver IC, the dual interfaces of 24PIN MIPI and I2C are mature and highly reliable.

Ultra-thin Module Thickness:

• The TFT display module is only 1.84 mm thick, and the total thickness of this 5.5 inch touch display module reaches 3.74 mm with optical bonding CTP, which effectively saves installation space.

Industrial 5.5 inch Capactive Touch Screen:

• Combined with the G+G capacitive touch panel, this all-in-one touch display module features high integration and is easy for embedded secondary development.

Advantage in Power consumption and cost:

• With moderate power consumption and cost-effective design, the 5.5 inch Touch Display module is ideal for industrial, vehicle-mounted, handheld and other scenarios that prioritize stability and cost performance.

Applications:

Featuring a classic portable size that balances display area and installation space,  the 5.5 inch all-in-one touch display module is widely applied to embedded display devices including handheld terminals, industrial PDAs, logistics scanners, vehicle dashboards, video intercoms, portable detectors and smart walkie-talkies.

The model#FT-05524-B-C-A, is easy to use and serves as a 5.5 inch reliable solution for embedded display applications.
